Pro 2000
- Working Width: 7 feet (2.1 meter)
- Tractor Power: 50 HP
- Efficiency 4.5 ltr/Hour
- Working speed: 1500 RPM
- Laser Range: 1000 mtr (500 mtr Radius)
- Hyd. Pressure: 250 Bar Max
- Blade: Special Steel 125×12 mm Reversible
- Type: 600×16 Agriculture, 6.00-16 mm
- Operating Voltage: 12 Volt DC
- Mast: Hand Driven Gear Mast
- Axel: 2 Axels, 4 Tyres, Cross Type
Rotary Transmitter
- Operating Range*: 1500 meter (Radius 750 mtr)eature 1
- Self – Leveling Accuracy**: ±1 mm @ 30 meters
- Rotating Speed: 600 RPM
- Laser Diode (type): 4.5 mW, Visible Red
- Manual Tilt: Upto ± 7 degree Power 1 Watt
- Battery: 12 V External
- Battery Life: 72 Hours with Full Battery
- Operating Temperature: 0 to 50° C
- Storage Temperature: 0 to 60° C
- Dust / Water Resistant: IP65
- Protection: Over Voltage, Low Battery, Reverse polarity
- Weight: 2.5 kgs
- Dimensions: 200 x 250 x 175 mm
Receiver
- Voltage: 12V DC ± 20%
- Max Current Consumption: 200 mA
- System Accuracy: ±5 mm
- Laser Requirement: All Rotating Lasers (HeNe or IR)
- Dust / Water Resistance: IP65
- Pulse Display: 10 Pulses per second
- Protection: Reverse Polarity
- Communication: 1 Wire
- Weight: 2 Kg
Control Box
- Display: Seven Segment LED, Visible in Day Light, Adjustable in Brightness
- Switch: Tour Sensor Switch Suitable for Dusty Condition
- System Accuracy: ±5 mm
- Control: Programmable
- Timer: Running Timer
- Charge: For 12V Battery with Protection
- Working Mode: 10 User Modes Programmable
- Indications: Working Channel, Time & Errors (LED for Up, Down, Link & Auto)
- Protection: IP65
- Connectors: Silver coated, Chroe plated atll weather bend proof
- System Voltage: 12VDC
- Cable: 1.5 mm RR Kabel / Finolex
